Electric Motors
Pfuko
Low Voltage Motors
0.37kW to 1000kW in standard design
HIGH PERFORMANCE DESIGNS ACROSS THE SPECTRUM ALSO AVAILABLE
Features
These motor’s are held in stock and are locally wound in accordance to manufacturers specifications for standard or special requirements with short deliveries.
Additional information
| Voltage (V) | 400, 525, 690 and 1000 volt |
|---|---|
| Output Power (kW) | 0.37kW to 1000kW in standard design |
| 355kv - | 3PH-MOT.PFU- 1LAB 355 - 4PB90-Z |
| 132kv - | 3PH-MOT.PFU- 1LAB 132 - 4PB90-Z |
| 250kv - | 6PH-MOT.PFU- 1LAB 250 - 4PB90-Z |
Enquire
Pfuko
Aluminium Motors
Rated output: 0.09 to 11kW
Can be supplied in IE1, IE2, IE3 and IE4
Features
Energy saving, High Efficiency
Additional information
| Voltage (V) | 400 and 525 Volt available |
|---|---|
| IP55 protection | Energy saving, High Efficiency |
Dimensions
Enquire
Pfuko
Medium Voltage Motors
3.3KV, 6.6KV, 11KV and 13.8 KV
Designed to IEC specification
Features
IP55 with class F insulation system
Additional information
| Kilowatt range: | 630kW – 20 000kW |
|---|---|
| Frame size: | 710 – 1000 |
| Speed: | 2, 4, 6, 8, 10 & 12 Poles |
| Voltage: | 3.3kV, 6.6kV & 11kV (+-10%) |
| Enclosure: | IP55, CACA |
| Cooling: | IC01, IC411 & IC611 |
| Mounting: | Foot or Flange – Vertical or Horizontal |
Enquire
Pfuko
Geared Motors
Wide variety of Gearboxes
Large ranges of Gearbox mounting are available
Features
A standard IEC shaft-mounted motor is used, eliminating the need for special motor shafts or adaptors. This design reduces downtime, as the gearbox is fully sealed to prevent oil leakage, and a standard IEC electric motor can be easily fitted without any modifications.
The “WEM” brand of high-efficiency electric motors is also compatible with additional features such as brakes, forced cooling, or encoders, making them ideal for Variable Speed Drive (VSD) applications.
Additional information
| 2.2 Geared motor | 3PH-MOT.PFU- 1LAB 2.2 - 4PB90-Z |
|---|---|
| Helical bevel geared motors | Shaft mounted geared motors |
| Parallel shaft geared motors | Worm geared motors |
| Agitator drives | System adapter |
| IP55 protection | Helical geared motors |
| Input shaft |
Enquire
Pfuko
CABLE, ELECTRICAL: 481154
Pfu. TC6/11KV.0002.64MM Pfuko cables
- CABLE, ELECTRICAL: TYPE: FLEXIBLE TRAILING ,
- CABLE DIAMETER: 64 MM , CONDUCTOR QUANTITY: 6 , ELECTRICAL RATING: 6/10 KV ,
- WEIGHT PER UNIT MEASURE: 6500 KG/KM , OPERATING TEMPERATURE: 90 DEG C ,
- APPLICATION: POWER SUPPLY , INDUSTRY STANDARD: DIN VDE 0250-813; SANS 1520-2 ,
- MANUF P/N: 20370743 VICTOR INDUSTRIAL EQUIPMENT (PTY) LTD
Pfuko
CABLE, ELECTRICAL: 51213
Pfu. TC6/11KV.0001.68MM Pfuko cables
- CABLE, ELECTRICAL: TYPE: 611 ECC , CABLE
- DIAMETER: APPROX 68 MM , CONDUCTOR
- QUANTITY: 6 CORE , CONDUCTOR SIZE: 3 X 70; 2 X 16; 1 X 35 MM2 , CONDUCTOR
- INSULATION: RUBBER , ELECTRICAL RATING: 6.35 - 11 KV , OPERATING TEMPERATURE: 30 - 45 DEG C ,
- APPLICATION: TRAILING , INDUSTRY STANDARD: SABS 1520 PART 2 , MANUF P/N: 791497 ABERDARE , FFT: ROLL = 300 M
Pfuko
ELECTRICAL CABLE
IP 66 Pfuko cables
- Rubber trailing cable round. 4 x 70mm core, Rated amps 220A, 450/750v, OD 46mm. IP 66, PFU/4C/70RUB-TRAIL
- Rubber trailing cable round. 4 x 95mm core, Rated amps 265A, 450/750v, OD 46mm. IP 66, PFU/4C/95RUB-TRAIL
- Rubber trailing cable round. 4 x 120mm core, Rated amps 310A, 450/750v, OD 57mm. IP 66, PFU/4C/120RUB-TRAIL
- Rubber trailing cable round. 4 x 185mm core, Rated amps 405A, 450/750v, OD 76mm. IP 66, PFU/4C/185RUB-TRAIL
